Australian Code Compliant Certifications State to State Annual Updated Certification
Specification
STEEL
Grade: G300
Thickness: 1.2mm
Galvanised coating: Z275
SCREWS
TOP PLATE
Type 17 Burmon square drive
65mm x 10 gauge galvanised
RAFTER
Type 17 Burmon hex head
35mm x 12 gauge
Compliance
The Burmon Cyclone Bracket is fully certified and tested for use in accordance with AS1684 Residential Timber Framed Construction.
Notes
- The Limit State Design capacities for the Burmon Cyclone Bracket resisting wind uplift are as shown in these tables. Design capacities have been obtained from laboratory testing and procedures given in AS1720.1.
- Wind Uplift capacities are baded on AS1720.1:2010 using k1=kt, for use in conjunction with AS/NZS 1170:2002 load code.
- The specified Burmon Screw must be used in conjunction with the Burmon Cyclone Bracket to achieve load ratings as per load tables.
- Cyclone Bracket (Australian Patent 2013209390) is certified by Registered Structural and Civil Engineers for the Australian Building Industry in accordance with the relevant Australian Standards and Building Codes. Cyclone Bracket is structurally adequate provided it is installed and used in complete accordance with the guide on Burmon brochures and websites.
Load Data
LIMIT STATE DESIGN CAPACITY (kN) | |||
Number of fixings | Timber Joints | ||
JD4 | JD3 | ||
8 | 9.4 | 13.0 | |
12 | 14.1 | 19.5 | |
Fixing Guide
Number of screws | Position |
8 | 4 screws into top plate |
12 | 6 screws into top plate |
ALSO AVAILABLE
Use Burmon Cyclone Bracket Extreme for even higher load rating.
This Engineered Building Product complies with the AS/NZS 1170 Loading Code
Technical Info & Downloads
Note: DWG, EASM, STEP and EPRT 3d Models may be viewed using free EDrawings Viewer software
